Description
WED-2018V - Veterinary Ultrasound | Keebomed Inc | SALE
With revolutionary technology of full digital beam-forming, WED-2018 provides the excellent image quality with high resolution and definition. The selectable multiple transducers, powerful measuring and analysising software packages extend its application to broader fields.
Features New Technology: Full digital beam forming technology, Probe automatic identification, Gama correction, histogram, edge-enhancement, Automatic report generation(Normal/OB), Scanning angle adjustment, 8-16 Level scanning depth adjustment, USB2.0 for real-time picture uploading to PC.
Main Features:
1) Scanning mode: Convex/linear/micro-convex
2) Display modes: B, B+B, B+M, 4B
3) Scanning depth: 240mm (max. )
4) Gray scales: 256
5) Cine-loop: 829 frames (max. )
6) Image permanent storage: 32 frames
7) Image conversion: Up/down, left/right, black/white
8) Local zoom: 2 times both in real-time and frozen
9) Measurement: Distance, circumference, area, volume, EF rate, heart rate
10) OB measurements: BPD, GS, CRL, FL, AD, HC, AC, EDD, GA, FW
11) Probes selectable: Convex, linear, micro-convex, transvaginal and endorectal
12) Monitor: 10.4 inch TFT color LCD
13) Body marks: 40
14) Comment: Date and time, name, sex, age, doctor, hospital, annotation (whole screen comment input)
15) Wide application: Abdominal, OB/GYN, urology, cardiology, small parts examination
16) Weight: 2kg (one probe included)
17) Packing dimensions: 470 x 380 x 220 mm
18) Power supply: 100V~130V/220V~240V, 50/60Hz
19) Standard configuration: C3-1/60R/3.5MHz Convex
20) Options:
L3-1/7.5MHz linear
C1-6/20R/5.0MHz micro-convex
EC1-1/13R/6.5MHz transvaginal convex
EL3-1/7.5MHz endorectal linear
Video printer / laser printer
Optional rechargeble battery
Car charger
